Nahrát soubor a vytisknoutI wanted a free-standing paper towel holder that both kept things tidy and made it easy to tear one sheet at a time. This design went through a few iterations and failures until I got something that works well. I printed it in Prusament Yellow gold, but i'll probably re-print in another color, because i've decided I don't love this color. Detailed instructions are below. Don't be scared by the detail though, this is not a hard print to make and assemble… I just want people to succeed the first time! Printing Instructions: Base choice (choose one) • Stock base • 4 Hole Hold-down version • Designed to screw into something heavy or stable to give the holder extra heft, or to secure it to something. Enables easier 1-handed use. Rod Variations: • Stock rod • Total height with base = 240 mm. • Extension Rod • Extra spacing rod to bring total height to 320 mm, above most standard paper towel rolls. Print this in addition to stock if you want the center pillar to rise above the towels. Filament choice The flex required in the arm is modeled and tested with PETG filament (Prusament, to be specific). That flex might not work with something stiffer like PLA, and you wouldn't want to use PLA anyways, as the creep over time would weaken the mechanism. I strongly recommend using PETG or another creep-resistant filament (not nylon). Filament for the base should something reasonably stiff. I used PETG, but PLA might also be fine here. General print settings for success Except where noted below, I recommend the following settings: • 0.16 mm or 0.2 mm layer height • 3-4 walls, except for arc arm, which should be printed solid with all walls (set to ~6-8 should be fine) • 15% cubic or gyroid infill, as you please • 4-6 top/bottom layers, as you wish. I used 5 at 0.16 mm height. Modifier objects to increase base part strength (important!) Early versions of this design suffered from buckling of the base (it was too thin vertically and not reinforced). This improve
